一、前言
原来对于单应用将生成的图形验证码存在Session会话中,但是在分布式环境在,当请求切换的cluster的备机,备机上没有UUID关联的验证码数据。因此,在分布式环境中,需要将UUID的验证码存储在Redis中,提交的时候统一根据UUID从内存中加载并验证,另外生成的图形验证码通过Base64.encodeBase64String转码后和UUID一起以JSON数据格式返回前端,这样生成的base64的验证码的数据可以直接贴在img标签的src属性中渲染显示。
二、代码示例
1.VerificationCodeController中通过接口2个接口分别获取返回图形的UUID及图形的Base64加密码接口、通过Img标签的src属性赋值图形加密串渲染出图形
2.通过/generateCode.do接口返回JSON的UUID和图形码的加密串,如下图
通过img标签将就可以将base64的加密字符串渲染为图形码图片,如下图所示
